机械制图与计算机绘图习题集（21世纪技能创新型人才培养系列教材·机械设计制造系列）
本习题集作为《机械制图与计算机绘图》教材的配套习题集。本习题集以培养学生创新能力和综合素质为出发点，选题新颖，内容丰富，知识点覆盖全面，主要特点如下：（1）贯彻最新机械制图技术和制图国家标准。（2）按照知识点编撰，习题的编排由易到难，循序渐进，以适应不同专业和不同层次教学的要求。（3）习题灵活多变，具有一定的深度和广度，有利于拓宽学生的知识面。（4）习题与生产岗位实际紧密结合，有较强的针对性和实用性。（5）配套习题集答案，方便教师授课和学生学习。
作业一 线型练习
作业指导
一、图名
图名为“线型练习”
二、内容
按图形要求绘制各种线段。
三、目的
熟悉图幅、图线及字体等制图标准，初步掌握绘图仪器与工具的正确使用方法。
四、要求
1. 选用A4 幅面的图纸，鉴别图纸正反面，竖放，正确固定图纸，用正确的线型绘制图框线及标题栏。
2. 绘图比例1∶1，图面布置要匀称，同类图线应粗细一致，作图要准确。
3. 绘制同心圆时，应先画小圆在画大圆。
4. 绘制完底稿后要认真检查，再按图线标准描深。
5. 根据例图正确标注尺寸，字体工整。
6. 标题栏中的图名、校名用10 号字，日期用3.5 号字，其余均用5 号字书写。
7. 保持图面清洁。
