24V Thermostat Controller Switch Temperature Sensor Digital LED Microcomputer
- Operating Voltage: DC 24V
- Measurement Range: -50 to 110 Celsius (-58 to 230 F)
- Elaboration Precision: +/-0.1 Celsius
- Control Precision: 0.1 Celsius
- Backlash Precision: 0.1 Celsius
- Refresh Rate: 0.5s
- High Temperature Protection: 0 to 60 Celsius (32 to 230 F)
- Temperature Sensor Type: 10K 0.5% NTC
- Operating Temperature: -10 to 60 Celsius (14 to 140 F)
- Compatible Load: 10A/20 A 220VAC; 20A 14VDC
- Power Consumption: Less than and equal to 35mA (Static), Less than and equal to 65mA (relay closure)
- Module Size: 48x29x32mm / 1.89x1.14x1.26 inch (LxWxH)
- Press STC key and the LED will flash.
- Press STC (+) and C/F (-) key to reach the set temperature value, wait for 3s, and the module will automatically save the parameters and exit.
- Indicator: Lights on, relay closed; Lights out, relay disconnected.
- Red: Measuring Temperature; Blue: Setting Temperature
- LL: Means the sensor is open
- HH: Indicates that the temperature exceeds the measurement range of the module
- --: Indicates that the module is under high temperature protection
- Programmable Thermostat Introductions (Code, Explain, Setting range, Factory setting):
- P0, Heating/Cooling, H/C, C
- P1, Return difference, 0.1-30, 2
- P2, Set limit maximum, +110, 110
- P3, Set limit minimun, -50, -50
- P4, Temperature correction, -15 - +15, 0
- P5, Delay start, 0-10, 0
- P6, High temperature alarm, -50 - +110, OFF
- P7, Celsius/Fahrenheit, CS/FH, CS
- P8, Factory reset, ON-OFF, OFF
- Size: 48mm (length) * 29mm * wide Depth: 32mm / 1.89x1.14x1.26 inch
- Hole size: 46 * 26.5mm / 1.81x1.04 inch
