PCA9306 I2C Level Translator Board Dual Bidirectional Voltage Level Translator Board Module Level Conversion Module
- BI-DIRECTIONAL, HIGH EFFICIENCY CONVERSION: PCA9306 module is equipped with bi-directional level conversion function, which can process two sets of signals at the same time to realize data interaction between devices in different voltage domains and effectively improve communication efficiency.
- PLUG AND PLAY, CONVENIENT DEVELOPMENT: breakout board design, no need to build complex circuits, through a simple connection can be quickly applied to the project development, effectively shorten the development cycle, reduce the threshold of hardware design.
- WIDE VOLTAGE ADAPTATION, STRONG COMPATIBILITY: Supports bi-directional conversion of multiple voltage combinations, and can be flexibly adapted to 1.0V, 1.2V, 1.8V, 2.5V, 3.3V, 5V and other voltage intervals, to meet the needs of all types of electronic equipment level conversion.
- LOW-LATENCY DESIGN, STABLE TRANSMISSION: Low-latency design with maximum propagation delay less than 1.5ns ensures fast and stable data signal transmission, applicable to I2C bus and SMBus protocol in standard mode, fast mode and fast mode+.
- WIDE RANGE OF APPLICATIONS AND RELIABLE PERFORMANCE: suitable for sensor data acquisition, embedded system development, IoT devices and other scenarios, providing reliable level shifting solutions for the communication of different voltage systems.
- Manufacturer: GYZOUKA
- Model Number: GYZOUKAiu8y4cw90m
- Part Number: GYZOUKAiu8y4cw90m
Specification:
This is a board for the PCA9306 dual bidirectional voltage-level translator. Because different parts sometimes use different voltage levels to communicate, voltage level translators can be the key to making different parts play nice.The PCA9306 is a dual bidirectional I2C-bus and SMBus voltage-level translator that's operational on the low side from 1.0 V to 3.6 V and on the high side from 1.8 V to 5.5 V. Simply apply your low- and high-side reference voltages to the VREF1 and VREF2 respectively, connect your I/O and drive the Enable pin high to open bidirectional voltage translation without the use of a direction pin!
Features:
2-bit bidirectional translator for SDA and SCL lines in mixed-mode I2C-bus applications
Standard-mode, Fast-mode, and Fast-mode Plus I2C-bus and SMBus compatible
Less than 1.5 ns maximum propagation delay to accommodate Standard-mode and Fast-mode I2C-bus devices and multiple masters
Allows voltage level translation between: 1.0 V Vref(1) and 1.8 V, 2.5 V, 3.3 V or 5 V Vbias; 1.2 V Vref(1)and 1.8 V, 2.5 V, 3.3 V or 5 V Vbias;1.8 V Vref(1)and 3.3 V or 5 V Vbias; 2.5 V Vref(1) and 5 V Vbias; 3.3 V Vref(1) and 5 V Vbias
Provides bidirectional voltage translation with no direction pin
Low 3.5 Ω ON-state connection between input and output port provides less distortion
Specification:
Model:PCA9306
Type:Level Translator
Color:red
Package list:
1 x PCA9306 board
