XTOOL A30M BiDirectional Scanner Auto Diagnostic Tool All System Car Code Reader

>>>xtool A30m V2.0 Most Cost Effective Bi-directional Scanner<<<

🔥[ 2025 Latest XTOOL A30M V2.0 - More New Features ] Wireless Bluetooth OBD2 Scanner Diagnostic Tool, suitable for most US, European, and Asian vehicles produced from 1996 to 2025 that comply with the OBDII standard. 🏆4000+Bidirectional Control/Active Test🏆FCA Autoauth & CANFD Protocl 🏆OE-Level Full System Diagnostic 🏆26+Popular Functions🏆Up to 8 Live Data Streams Graphing.

🔥[ Free Updated with Lifetime Access ] The XTOOL Anyscan A30M wireless OBD2 scanner includes free lifetime software updates for all app service functions. With a single payment, enjoy full access to diagnostics, reset tools, and maintenance features – no recurring fees. A budget-friendly choice for home car owners and DIYers.

🔥[ Bi-directional Control, Quickly Locate Problems ] The bi-directional scan tool enables you to send commands from your smartphone directly to the vehicle's ECU for active testing. This feature helps to quickly narrow down problem areas, such as A/C clutch, windows, doors, sunroof, etc., reducing the mechanic's diagnostic time and can help DIY users locate faults more easily.

🔥[ 26+ Popular Functions ] XTOOL A30M offers 26+ reset functions: Oil Light Reset, Throttle Adaptation, EPB Reset, Steering Angle Reset, DPF Regeneration, ABS Bleeding, Inject Coding, BMS Reset, and Airbag Reset etc. By these functions, you can save on unnecessary repair costs and reduce repair times significantly.

🔥[ Full System Diagnostics & Up to 8 Live Data Streams Graphing] Experience the power of an OE-Level Full System Diagnostic Scan Tool. XTOOL A30M can thoroughly scan all available systems, including Engine, Transmission, ABS, SRS, AC and more. Ensuring comprehensive insights into your vehicle's health. Experience intuitive graphing for detailed data in real-time, making it easier to identify issues and trends, etc

🔥[ FCA AutoAuth Access & CAN-FD Protocol] XTOOL A30M V2.0 allows you to access the FCA, which allows you to perform protected functions on FCA vehicles for Chrysler/Dodge/Jeep/Fiat, etc.(Note: just allows you to access the FCA, but you need to have your own FCA account).

🔥[ Stable Wireless Connectivity & Extensive Compatibility ] Embrace the future with XTOOL A30M's fast and stable wireless diagnosis. No more cable limitations – enjoy mobility up to 33 feet. It's the perfect compact diagnostic scanner for those who prefer wireless diagnostics. Compatible with 85+ American, European, and Asian car makes, providing an abundance of diagnostic options through BT connectivity with your smartphone

🔥[ 85+ Brand Vehicle Coverage ] Broad vehicle coverage, work on more than 85 brands, 10000+ cars, and it is still growing.

🔥[ Multi-lingual ]23+  languages optional, default in English, send us S/N to change to Spanish, French, etc.

🔥[ Support Both iOS (above 10.0)and Android(above 5.0) devices ]You don't need to pay for two devices. And you can also use the Microsoft “Your Phone” app to download and use the "Anyscan" APP. Please be reminded that the main interface of iOS/Android Smartdevice is different.

🔥[ User-Friendly APP】The XTOOL A30M is paired with an easy-to-use mobile app that delivers a smooth, intuitive experience. Effortlessly navigate features, access detailed vehicle information, and generate diagnostic reports — all with just a few taps, making every step of the process fast and hassle-free.

🔥[ Enjoy expert assistance and a 2-year warranty for total peace of mind long after your purchase. 】Having trouble registering or missing your activation code? No worries! Please double-check the product packaging for the code. If you still can't find it, or if you're facing issues registering, come to us with your device's S/N. We're here to help you get everything set up! Or experiencing unstable Bluetooth connections or slow software updates? Please check your connection and try again. If the issue persists, come to us with your device's S/N and our support team will guide you to a quick resolution!

>>>26+HOT USE SPECIAL FUNCTIONS<<<

• Oil Light Reset：Reset the Engine Oil Life System, which calculates the optimum oil life change interval based on the vehicle’s driving conditions and climate

• ABS Bleeding:Use to replace the rear brake distributor pump or the front brake distributor pump. When Severe brake fluid shortage,change the brake fluid

• Electronic Parking Brake (EPB) :Use to reset the electronic parking brake system and brake pads, which also supports the brake pad replacement (retraction, release of the brake pump), G-sensor, and body angle calibration

• D/PF Regeneration:Manages D/PF regeneration, D/PF component replacement teach-in, and D/PF teach-in after replacing the engine control module

• Injector Coding:Can write the identification code of the fuel injector into the Control Unit so that can recognize and work normally

• BMS Reset:Allows the scan tool to evaluate the battery charge state, monitor the close-circuit current, register the battery replacement, and activate the rest state of the vehicle.

• Steering Angle Sensors (SAS):Calibration permanently stores the current steering wheel position as the straight-ahead position in the SAS EEPROM.

• Gearbox Match:After changing the gearbox or changing the gearbox Module, use to re-match the engine and the gearbox

• Throttle Relearn:Enables you to make initial settings to throttle actuators and returns the “learned” values stored on Control Unit to the default state.

Also include:Instrucment Cluster,,Suspension,Windows Initialization,Gear Learning,Tire Upgrade,FRM Reset,EGR Relearn,Transported Mode,Seats Calibration,TPMS Reset,SRS Reset,Power Balance,etc..

NOTE:Functions vary by vehicles,pls provide vehicle info to consult us to check compatibility before purchase

>>>BI-DIRECTIONAL CONTROL,ACTIVE TEST SCANNER<<<

The scan tool can request information or command a module to perform specific tests or functions. Reinitialization and reprogramming would also be included in the list of bidirectional controls. Users could check the individual part to see which part is working properly by actuation test.

>>>FULL SYSTEM DIAGNOSTIC SCANNER<<<

The Diagnosis System supports 5 basic diagnosis functions:

✅ Read Module Information:To read Module-related software and hardware versions, models, and production date of the diesel engine, part number, etc.

✅ Read & Clear Trouble Code:Read trouble codes (DTCs) that are stored in Control Unit. Will give specific detailed definitions and explanations to help you locate and eliminate the car fault.

✅ Live Data:Displays the real-time parameters of the ECU

✅ Actuation Test (Bi-Directional Control):Can request information or command a module to perform specific tests or functions. Reinitialization and reprogramming would also be included in the list of bidirectional controls.

✅ Freeze Frame:Will record the top prioritized DTC. Provides a snapshot of critical parameters at the moment DTC is set.

The diagnosis function can also access the electronic control unit (ECU) of all available vehicle control systems, including the engine,transmission, anti-lock braking system (ABS), airbag system (SRS), body control module (BCM), battery management system (BMS), tire pressure monitoring system (TPMS), steering and suspension system (SAS) and perform various actuation tests.

NOTE: Functions is not supported by all models,pls provide vehicle info to consult us to check compatibility before purchase

>>>ENHANCED FULL 10 OBD2 MODES TEST<<<

OBDII implements the standardized digital communications port and diagnostic trouble codes (DTCs) which allows scan tools to communicate with the PCM of the vehicle. And the Anyscan is able to access the OBDII diagnostic functions as follows

✅ Read Trouble Codes:Read trouble codes (DTCs) that are stored in Control Unit

✅ Clear Trouble Codes :Used to clear all emission related diagnostic data such as DTCs, freeze frame data, and manufacturer specific enhanced data from the vehicle’s PCM

✅ Live Data:Displays the real-time PID data from Control Unit.

✅ Read Freeze Frame:Will record the top prioritized DTC. Provides a snapshot of critical parameters at the moment DTC is set.

✅ Read Module Information:To read Module-related software and hardware versions, models, and production date of the diesel engine, part number, etc.

✅ Component Test:This service enables bi-directional control of the ECM so that the diagnostic tool is able to transmit control commands to operate the vehicle systems

✅ On-Board Monitor Test:Allows you to view the results of On-Board Monitor tests.

✅ O2 Sensor Monitoring Test:Allows the PCM to verify that the O2 sensors are properly calibrated and functioning without noticeable deterioration under normal engine operating conditions

✅ I/M Readiness:Used to check the readiness of the monitoring system

>>>10000+VEHICLES SUPPORT & MULTILINGUAL FREE CHANGING<<<

The languages supported by the device are listed in Setting.  The default language is set as English, if you need to switch to other languages,pls provide S/N of scanner send to us

◼ How to change the language of your software?

✅Step1: Contact your dealer and leave a message about the language you need and the S/N of your device, The technician will modify the language configuration for you in the backend system.

✅Step2: Settings->Language->Choose language

✅Step3: Back to Updates to update all the software again
